WSI 4/LD 10-36V AC/DC 3039188659
Product number
1276309
Sikringsklemme, med LED Merketverrsnitt: 4 mm², Tilkoblingstype: Skru tilkobling, Isolasjonsmateriale: Wemid, Farge på Isolasjonsmateriale: Sort, Installasjon: TS 35 Sikring 5x20
Product details
Technical specifications
Type of fuse insertG-fuse 5x20 mm
Type of fuse holderScrewable
Type of indication element for defect indicationLED
Supply voltage for defect-indication36 ... 36 V
Voltage type for defect indicationAC/DC
Connectable conductor cross section fine-strand without cable end sleeve0.5 ... 4 mm²
Connectable conductor cross section fine-strand with cable end sleeve0.5 ... 2.5 mm²
Connectable conductor cross section solid-core0.5 ... 4 mm²
Connectable conductor cross section multi-wired1.5 ... 4 mm²
Rated current In6.3 A
Rated voltage36 V
Type of electrical connection 1Screw connection
Type of electrical connection 2Other
Number of levels1
Mounting methodDIN rail (top hat rail) 35 mm
Product codes
SAPGCN411
PLC1276309
STK1276309
GTIN/EAN4032248492077
Manufacturer part number3039188659
Vendor material number1886590000
Basic information
Package measurements (L x W x H)0.07 x 0.008 x 0.05 mm
Package volume0.028 l
Package weight0.01 kg
Base uniteach
Package units50
Usage quantity1
UNSPSC39131410
BrandWEIDMÜLLER
