LED-stripe 4 meter
Product number
3202569
Tunable og dimbar LED-stripe laget for bruk med LED-75. 4 meter.
LST-01 er en tunable og dimbar LED-stripe laget for bruk med LED-75. Den er delbar i 50 mm segmenter og klassifisert inntil IP66. Høy tetthet mellom LED-lysene gir et prikkfritt utseende inne i diffusoren, selv med tynne profiler. LED-stripe kan installeres med den medfølgende dobbeltsidige tapen i profiler som er minst 13 mm brede.4 meter.
Product details
Technical specifications
ModelStrip
Mounting methodSurface mounting/recessed mounting
Lamp typeLED not exchangeable
Number of nodes per meter140
Lamp power per meter9.6 W
Luminous flux per meter960 lm
Voltage typeDC
Lamp voltage24 ... 24 V
Type of control gearLED operating device voltage-controlled
Suitable for dimmertrue
Exchangeable control geartrue
Energy efficiency class of the light source according to EU regulation 2019/2015F
Rated life time L70/B50 at 25 °C60000 h
Degree of protection (IP)IP66
Degree of protection (NEMA)4X
Product codes
SAPCZW280
PLC3202569
STK3202569
GTIN/EAN7330018113090
Manufacturer part numberLST-01-4M
Vendor material numberLST-01-4M
Basic information
Package measurements (L x W x H)4000 x 13 x 9 mm
Package volume0.468 l
Package weight0.326 kg
Base uniteach
Package units1 / 20 / 30
Usage quantity–
UNSPSC32111503
BrandPLEJD
