SOLID STATE RELEER SSR UTG. MODUL 230VAC/5A
Product number
4134760
RP1A23D5M1 Solid State rele
Interface Solid state rele (SSR). PCB-rele. Nom. nettspenning inntil 230VAC. Maks. 5A. Styreinngang 5-34VDC. Kobling i nullgjennomgang. Montert på sokkel.
Product details
Technical specifications
Modular versiontrue
Rated control supply voltage AC 50 Hz0 V
Rated control supply voltage AC 60 Hz0 V
Rated control supply voltage DC5 ... 34 V
Voltage type for actuatingDC
Number of phases1
Switching at zero-crossingtrue
Rated operation current Ie at AC-10 A
Rated operation current Ie at AC-3# A
Rated operation current Ie at AC-515 A
Rated operation current Ie at AC-53a3 A
Rated operation current Ie at AC-53b0 A
Operating voltage12 ... 265 V
Product codes
SAPCLU417
PLC4134760
STK4134760
GTIN/EAN5350035323229
Manufacturer part numberRP1A23D5M1
Vendor material numberRP1A23D5M1
Basic information
Package measurements (L x W x H)50 x 90 x 15 mm
Package volume0.068 l
Package weight0.023 kg
Base uniteach
Package units1
Usage quantity–
UNSPSC32000000
BrandCARLO GAVAZZI
