IPS CIV 3125BU9W
Product number
1564893
IPS TOUGH&SAFE CIV 3125BU9W INNFELT APPARAT INNTAK IP67
HAUGE innfelt apparatinntak 125A, 3P+J, 9h, 200-250V 50-60Hz Normer: EN 60309-1 og EN 60309-2. Kapslingsmateriale: Termoplastisk polyester. Innsatsmateriale: Glassfiberarmert polyamid. Har pilotstift for elektrisk forrigling. Målskissene viser hvordan apparatinntaket må monteres for at lokket på skjøtekontakten skal virke som 'låsing', dette for at kravene i EN 60309-2 skal oppfylles. Når apparatinntaket ikke er i bruk kan det beskyttes/tettes med beskyttelseshette GP 125, el.nr. 15 640 86
Product details
Technical specifications
IEC-amperage125 A
Amperage according to UL/CSA (for UL-version)125 A
Voltage according to EN 60309-2200-250 V (50+60 Hz) blue
Rated voltage200 ... 250 V
Rated frequency50 ... 60 Hz
Number of poles4
Clock hour position9 h
Identification colourBlue
RAL-number7001
Degree of protection (IP)IP67
Connection systemScrewed terminal
Construction typeSurface mounted device plug
Phase inverterfalse
Insert directionStraight
MaterialPlastic
Product codes
SAPGAD900
PLC1564893
STK1564893
GTIN/EAN7392696672009
Manufacturer part number2CMA167200R1000
Vendor material number2CMA167200R1000
Basic information
Package measurements (L x W x H)145 x 122 x 122 mm
Package volume2.158 l
Package weight0.84 kg
Base uniteach
Package units1
Usage quantity1
UNSPSC39121413
BrandAMPHENOL
