New
Frekvensomformer ACS580-01-06A7-2+B056
Product number
4188223
230V/3-fas/IP55/1,1kW/6,7A
ACS580 er en serie med frekvensomformere som passer utmerket i de fleste industrier. Dette er ikke vår toppmodell(ACS880), men har samtidig mye av samme funksjonliteten for krevende applikasjoner. Bruk ETIM dataen her for å finne rett modell, eller "ABB Drive and Motor Selector"
Product details
Technical specifications
Mains voltage200 ... 240 V
Mains frequency50/60 Hz
Number of phases input3
Number of phases output3
Max. output frequency500 Hz
Max. output voltage240 V
Nominal output current I2N6.7 A
Max. output at quadratic load at rated output voltage1.1 kW
Max. output at linear load at rated output voltage1.1 kW
Power consumption72 W
Relative symmetric net frequency tolerance5 %
Relative symmetric net voltage tolerance10 %
Number of analogue outputs2
Number of analogue inputs2
Number of digital outputs3
Product codes
SAPDFQ710
PLC4188223
STK4188223
GTIN/EAN6438177591320
Manufacturer part number3AXD50000417506
Vendor material number3AXD50000417506
Basic information
Package measurements (L x W x H)233 x 128 x 403 mm
Package volume12.019 l
Package weight4.8 kg
Base uniteach
Package units1
Usage quantity–
BrandABB
