New
Frekvensomformer ACS580-01-047A-2+B056
Product number
4188229
ACS580-01-047A-2+B056 PN: 11.0 kW, IN: 46 A
No product description available.
Product details
Technical specifications
Mains voltage200 ... 240 V
Mains frequency50/60 Hz
Number of phases input3
Number of phases output3
Max. output frequency500 Hz
Max. output voltage240 V
Nominal output current I2N46.7 A
Max. output at quadratic load at rated output voltage11 kW
Max. output at linear load at rated output voltage11 kW
Relative symmetric net frequency tolerance5 %
Relative symmetric net voltage tolerance10 %
Number of analogue outputs2
Number of analogue inputs2
Number of digital outputs3
Number of digital inputs6
Product codes
SAPDBB762
PLC4188229
STK4188229
GTIN/EAN6438177591382
Manufacturer part number3AXD50000417568
Vendor material number3AXD50000417568
Basic information
Package measurements (L x W x H)1 x 206 x 490 mm
Package volume0.101 l
Package weight0.013 kg
Base uniteach
Package units1
Usage quantity–
UNSPSC39121007
BrandABB
