Frekvensomformer ACS580-01-039A-4+B056
Product number
4101110
400V/3-fas/IP55/18,5kW/38A
ACS580 er en serie med frekvensomformere som passer utmerket i de fleste industrier. Dette er ikke vår toppmodell(ACS880), men har samtidig mye av samme funksjonliteten for krevende applikasjoner. Bruk ETIM dataen her for å finne rett modell, eller "ABB Drive and Motor Selector"
Product details
Technical specifications
Mains voltage380 ... 480 V
Mains frequency50/60 Hz
Number of phases input3
Number of phases output3
Max. output frequency500 Hz
Max. output voltage480 V
Nominal output current I2N38 A
Max. output at quadratic load at rated output voltage18.5 kW
Max. output at linear load at rated output voltage18.5 kW
Relative symmetric net frequency tolerance5 %
Relative symmetric net voltage tolerance10 %
Number of analogue outputs2
Number of analogue inputs2
Number of digital outputs3
Number of digital inputs6
Product codes
SAPCYH228
PLC4101110
STK4101110
GTIN/EAN6438177459392
Manufacturer part numberAS58001039A4BJ400
Vendor material numberAS58001039A4BJ400
Basic information
Package measurements (L x W x H)733 x 237 x 206 mm
Package volume35.787 l
Package weight15 kg
Base uniteach
Package units1
Usage quantity–
UNSPSC32000000
BrandABB
