EFF.BR T1B 160 R40 3P F FC 1SDA050874R0001
Product number
4376904
T1B 160 TMD40-630 3p F FC Cu (1╫70mm2)
Eff.br T1B 160 R40 3P F FC EFF.BR T1B 160 R40 3P F FC
Product details
Technical specifications
Rated permanent current Iu160 A
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz16 kA
Overload release current setting28 ... 40 A
Adjustment range undelayed short-circuit release500 ... 500 A
Device constructionBuilt-in device fixed built-in technique
Integrated earth fault protectionfalse
Type of electrical connection of main circuitScrew connection
Suitable for DIN rail (top hat rail) mountingfalse
Number of auxiliary contacts as normally closed contact0
Number of auxiliary contacts as normally open contact0
Number of auxiliary contacts as change-over contact0
With switched-off indicatortrue
Number of poles3
Position of connection for main current circuitFront connection
Type of control elementRocker lever
Product codes
SAPGAU747
PLC4376904
STK4376904
GTIN/EAN8015644512866
Manufacturer part number1SDA050874R0001
Vendor material number1SDA050874R0001
Basic information
Package measurements (L x W x H)0 x 0 x 0 mm
Package volume0 l
Package weight0.1 kg
Base uniteach
Package units1
Usage quantity–
UNSPSC32000000
BrandABB
