CONTACTOR AF80-30-00-13
Product number
4117592
KONTAKTOR AF80-30-00-13 100-250V
AF80 contactors are used for controlling power circuits up to 690 V AC and 220 V DC. They are mainly used for controlling 3-phase motors, non-inductive or slightly inductive loads. AF... contactors include an electronic coil interface accepting a wide control voltage Uc min. ... Uc max. Only four coils cover control voltages between 24...500 V 50/60 Hz or 20...500 V DC. AF contactors can manage large control voltage variations. One coil can be used for different control voltages used worldwide without any coil change. AF contactors have built-in surge protection and do not require additional surge suppressors. The AF... series 1-stack 3-pole contactors are of the block type design. - Main poles and auxiliary contact blocks: 3 main poles, front and side-mounted add-on auxiliary contact blocks (mechanically-linked auxiliary contacts compliant with Annex L of IEC 60947-5-1. N.C. mirror contacts compliant with Annex F of IEC 60947-4-1) - Control circuit: AC or DC operated - Accessories: a wide range of accessories is available.
Product details
Technical specifications
Rated control supply voltage AC 50 Hz100 ... 250 V
Rated control supply voltage AC 60 Hz100 ... 250 V
Rated control supply voltage DC100 ... 250 V
Voltage type for actuatingAC/DC
Number of normally closed contacts as main contact0
Number of normally open contacts as main contact3
Type of electrical connection of main circuitScrew connection
Operating voltage AC 50 Hz1000 ... 1000 V
Operating voltage AC 60 Hz1000 ... 1000 V
Rated operation current Ie at AC-1, 400 V125 A
Rated operation current Ie at AC-3, 400 V80 A
Rated operation power at AC-3, 400 V37 kW
Rated operation power NEMA44.742 kW
Number of auxiliary contacts as normally open contact0
Number of auxiliary contacts as normally closed contact0
Product codes
SAPANY811
PLC4117592
STK4117592
GTIN/EAN3471523132931
Manufacturer part numberAF80-30-00-13
Vendor material number1SBL397001R1300
Basic information
Package measurements (L x W x H)126 x 70 x 116 mm
Package volume1.023 l
Package weight1.29 kg
Base uniteach
Package units1
Usage quantity–
UNSPSC39121529
BrandABB
